Product description
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Technical data2.1
Technical data for SF 40-2 – SF 220, part 1
Air coolingWater cooling
Type SF40-2 SF60-2 SF100-2 SF150 SF220
Dimensions
– Height (silenced) [inch] 57 57 57 69 79
– Height (super silenced) [inch] 77 77 77 89 99
– Width (silenced / super silenced) [inch] 64 64 79 93 89/101
– Depth [inch] 38 38 42 53 63
Weight
– silenced [lbs] 1470 1850 3377 4720 5735
– super silenced [lbs] 1540 1920 3487 4850 5955
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 76/71 78/73 80/73 79/74 83/74
– silenced / super silenced [dB(A)]
Measuring surface dimension
15/16 15/16 16/17 17/18
18/19
– silenced / super silenced [dB(A)]
Sound capacity level
91/87 93/89 96/90 96/92 101/93
– silenced / super silenced [dB(A)]
Max. sound pressure level [±3 dB(A)]
accord. to DIN 45635, part 13 75/70 77/72 79/72 73/71 79/71
– silenced / super silenced [dB(A)]
Measuring surface dimension
15/16 15/16 16/17 17/18 18/19
– silenced / super silenced [dB(A)]
Sound pressure capacity
90/86 92/88 95/89 90/89 97/90
– silenced / super silenced [dB(A)]
Compressor
max. final compression temperature [°F] 230 230 230 230 230
Volume flow according to ISO 1217 Part C
–p
max
= 100 psig [cfm] 48,7 – 195,3 64,4 – 257,6 114,1 – 448,6 171,3 – 685 256 – 1024
–p
max
= 115 psig [cfm] 45,6 – 182,6 61,8 – 247,2 106,6 – 427,3 162,4 – 650 246 – 985
–p
max
= 125 psig [cfm] 45,6 – 182,6 61,8 – 247,2 106,6 – 427,3 162,4 – 650 246 – 985
–p
max
= 150 psig [cfm] 41,0 – 163,5 55,8 – 223,9 92,7 – 370,8 144,1 – 576 222 – 886
–p
max
= 190 psig [cfm] 33,9 – 134,9 47,3 – 189,3 81,2 – 324,9 125,3 – 501 192 – 766
Drive motor
Rated power [hp] 40 60 100 150 200
Rated speed
– 60 Hz [min
-1
] 3600 3600 3600 3600 3600
Protection type TEFC TEFC TEFC TEFC TEFC
ISO class F FFFF
Electrical connection
Mains voltage
1
)
3
) [V] 460/575 460/575 460/575 460/575 460/575
Frequency
1
) [Hz] 60 60 60 60 60
Recommended fuse protection
2
) [A] 60/50 90/70 150/125 200/175 300/250
1
) Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
2
) Only for 460 V / 60 Hz. The fuse values change in the case of other mains voltages and frequencies.
3
) For the refrigeration compressed air dryer 230 V / 60 Hz are required.
