The Bogen BPA60 Power Amplifier has been designed to ful-
fill the power amplification requirements of professional and com-
mercial sound systems. The BPA60 supplies 60 watts RMS
output. Total harmonic distortion is less than 2% at rated output
from 50 Hz to 15 kHz with a frequency response of -2 dB from
20Hz to 20 kHz.
An input signal of only 300mV is required for full rated output
(75mV for low-impedance balanced input with accessory trans-
former TL600). Input impedances are: 50k, high-impedance un-
balanced; or 600 ohms, low-impedance balanced, with accessory
transformer TL600. Line-bridging may be achieved with Bogenʼs
TL100 accessory (transformer). Output impedances are: 8-
ohm/25V, 16-ohm, 25VCT, and 70V.
A Lo-cut filter provides 10 dB attenuation at 100 Hz. An input
level control (screwdriver-adjustable) allows higher input signal
level without overdrive.
An AC circuit breaker and transient protection diodes prevent dam-
age due to overloads. The amplifier is also thermally protected from
excessive temperatures.
An illuminated power switch is located on the front panel. Input
and output connectors, input level control, lo-cut filter switch, AC
circuit breaker, and auxiliary power receptacle are located on the
rear panel. The thermal breaker and accessory transformer socket
are located internally.
The amplifier operates from a 120V AC, 60 Hz source. The three-
wire line cord provides automatic grounding of the amplifier and
auxiliary receptacle when connected to a properly grounded three-
wire power outlet.
NOTICE: Every effort was made to ensure that the information in this guide
was complete and accurate at the time of printing.
However, information is subject to change.
WARNING: To reduce the risk of Fire or Electric Shock, Do Not Expose this
apparatus to rain or moisture.
Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases shall be placed on the apparatus.
WARNING: Only connect unit to AC mains outlet providing protective
earthing connection.
NOTE: Mains plug is used as disconnect device from the mains and shall
remain readily accessible and operable.
CAUTION: These servicing instructions are for use by qualified service per-
sonnel only. To reduce the risk of electric shock, do not perform
any servicing other than that contained in the operating instructions
unless you are qualified to do so.
Always follow these basic safety precautions when installing and using the unit:
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean unit with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong.
The wide blade, or the third prong, are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when not used for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE ANY FRONT/BACK
COVERS OR PANELS. NO USER-SERVICEABLE
PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point within an equi-
lateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions.
The lightning flash with arrowhead sym-
bol, within an equilateral triangle, is in-
tended to alert the user to the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute
a risk of electric shock to persons.
Description
