7
Frequency Resp. (-10dB)* 45 Hz to 20 kHz
LF Driver
8-inch Nominal Diameter Metal Alloy Cone
utilizing MLS (Magnetic Liquid Suspension)
HF Driver Co-axial Design; 1” Titanium Cone
Sensitivity (1 W/1m, 8Ω) 91 dB SPL
Max. SPL (@ 1m) 114 dB continuous, 120 dB Peak
Max. Power Input (cont.) 150W (8Ω) or 64W (70V)
Impedance Nominal 8Ω or 70V
Taps (70V only) 2W, 4W, 8W, 16W, 32W, 64W** (optional)
Input Terminations 8-Conducter Cable Color-Coded
Environmental Designed to meet or exceed Mil-Std-810E, IEC IP56
Installation Hole Depth 10-inches Max.
Enclosure Material
LLDPE (Linked Low-Density Polyethylene, UV-Inhibited)
Enclosure Color Green
Product Dimensions 17.25” H x 13” W x 12.25” D
Product Weight 14 lbs.
TECHNICAL SPECIFICATIONS
*Half-Space Response
**Requires simple wiring change inside G8 cabinet
