THE INTERIOR OF THE BOLEX
1
2
3
4
5
6 11
7 12
8 13
9
14
15
16
1 Daylight Spool 9 Pressure Pad Securing Screw
2 Upper Spindle 10 Lower Loop Former 3
Upper Loop Former 11 Audible Counter Control
4 Upper Sprocket 12 Spool Ejector
5 Pressure Pad Pin 13 Retaining Arm
6 Gate Pressure Pad 14 Film Knife
7 Loop Former Control 15 Lower Spindle
8 Lower Sprocket 16 Takeup Spool
10
A
To Next Page
