Bollhoff Portable C RIVSET - Page 9

Portable C
RIVSET
®
(10 - 50 kN) | WELTAC
®
(10 - 50 kN)
HE.18644_A © 08/2019
Abb. ähnlich / pic. similar
CLICK
1.
2.
RIVSET
®
WELTAC
®
Nieten / Riveting / Rivetage
SW2
M
T
= 3Nm
SW2
M
T
= 3Nm

Nietstempel/Riveting die/Rivet piston
SNS3M 3 mm Niet/rivet
SNS5M 5 mm Niet/rivet
SNS3M - 5500.322.048.5 SNS5M - 5500.322.048.6
Art.-Nr.
Item N°.
N° d‘article
Bezeichnung
description
déscription
Art.-Nr.
Item N°.
N° d‘article
Bezeichnung
description
déscription
5500.322.041.2
HE.12077
Stempel
Punch
Piston
5500.322.040.9
HE.12083
Stempel
Punch
Piston
5500.322.041.1
HE.12080
Distanzring
Spacer
Bague de distance
5500.322.041.1
HE.12080
Distanzring
Spacer
Bague de distance
5500.322.041.0
HE.12079
Ringmagnet
Ring magnet
Bague magnétique
5500.322.041.0
HE.12079
Ringmagnet
Ring magnet
Bague magnétique
5500.322.041.3
HE.12078
Rundfeder
Elastomer spring
Ressort élastomère
5500.322.039.0
HE.12084
Rundfeder
Elastomer spring
Ressort élastomère
VII
originalbedienungsanleitung
WORK SERVICE DON´T DO
General
safety rules
PRESS
PRESS

HE.3875
(71074308203)
2x HE.3875
(71074308203)
