Shaft-mounted gear units, series F:
(A13)
H1 H2 H3 H4 H5 H6
F102 1.2 1.3 0.70 0.80 0.80 1.1
F202 2.0 1.7 0.90 1.3 1.2 1.7
F203 2.3 1.8 1.2 1.5 1.8 1.8
F302 2.6 2.6 1.5 1.7 2.5 2.6
F303 2.5 2.5 1.5 1.6 2.4 2.5
F304 3.0 2.7 1.9 2.0 3.3 2.7
F402 5.5 4.4 4.5 3.6 5.6 4.9
F403 5.5 4.4 4.5 3.6 5.6 4.9
F404 5.3 4.3 4.3 3.3 5.5 4.4
F502 9.7 7.2 8.1 5.2 9.7 7.6
F503 9.7 7.2 8.1 5.2 9.7 7.6
F504 9.7 7.4 8.1 5.1 9.9 7.4
F603 14 11 7.9 11 15 11
F604 15 12 8.0 11 15 11
oil
[l
]
Life-time lubricated gear units.
Lubricant is not factory filled.
H1 H2 H3 H4 H5 H6
F102 0.95 0.95 0.95 0.95 0.95 0.95
F202 1.4 1.4 1.4 1.4 1.4 1.4
F203 1.8 1.8 1.8 1.8 1.8 1.8
F302 2.6 2.1 1.5 2.1 2.9 2.1
F303 2.6 2.1 1.5 2.1 2.9 2.1
F304 2.9 2.4 1.7 2.4 3.2 2.4
F402 5.0 3.9 4.0 3.1 5.1 4.0
F403 5.0 3.9 4.0 3.1 5.1 4.0
F404 5.3 4.3 4.3 3.3 5.5 4.4
F502 9.2 6.7 7.6 4.7 9.2 6.7
F503 9.2 6.7 7.6 4.7 9.2 6.7
F504 9.7 7.4 8.1 5.1 9.9 7.4
F603 14 10 7.4 10 14 10
F604 15 12 8.0 11 15 11
F703 23 20 9.7 16 24 19
F704 23 20 9.7 16 27 19
F803 40 34 16 29 42 31
F804 40 34 16 29 48 31
F903 71 59 32 49 76 55
F904 71 59 32 49 86 55
(A12)
oil
[l
]
