BONFIGLIOLI W Series

33
Bevel helical gear units, series A:
B3 B6 B7 B8 VA VB
A102 1.4 1.4 1.4 1.4 1.4 1.4
A202 2.3 2.3 2.3 2.3 2.3 2.3
A203 2.6 2.6 2.6 2.6 2.6 2.6
A302 3.2 3.2 3.2 3.2 3.2 3.2
A303 3.6 3.6 3.6 3.6 3.6 3.6
A412 4.0 4.1 4.1 4.7 5.2 4.4
A413 4.0 4.0 4.0 4.7 6.1 3.9
A502 4.9 8.1 4.7 8.4 11 9.2
A503 5.1 8.1 4.7 8.4 11 9.2
A504 6.3 8.2 5.3 8.3 13 9.1
A602 6.8 8.1 12 15 18 15
A603 6.8 8.1 12 15 18 15
A604 7.2 11 7.4 16 19 14
A703 10 14 10 15 20 14
A704 13 14 10 15 23 14
A803 15 22 15 26 35 22
A804 20 22 15 26 39 22
A903 31 35 37 44 66 39
A904 41 35 37 44 73 39
(A10)
oil [l]
(A11)
B3 B6 B7 B8 VA VB
A102 0.80 1.2 1.2 1.1
A202 1.2 1.7 1.8 1.5
A203 1.5 1.7 2.4 1.6
A302 1.8 2.3 2.6 2.1
A303 2.3 2.4 3.5 2.3
A412 4.0 4.1 4.1 4.7 5.2 4.4
A413 4.0 4.0 4.0 4.7 6.1 3.9
A502 4.9 8.1 4.7 8.4 11 9.2
A503 5.1 8.1 4.7 8.4 11 9.2
A504 6.3 8.2 5.3 8.3 13 9.1
A602 6.8 8.1 12 15 18 15
A603 6.8 8.1 12 15 18 15
A604 7.2 11 7.4 16 19 14
oil
[l]
see Annex 1 see Annex 1
Life-time lubricated gear units.
Lubricant is not factory filled.
