BORETTI IBRIDO TOP - Tegninger for Montering

129
NOBoretti Ibrido Top / Brukermanual - Installasionsräd
Heating grill
Lid handle
Control button:
side burner
Right cover
Self-tapping screws 6x
Left cover
Cast iron grill Lid
Electric ignition
Right cover strip
Side burner
Cover strip backside
Charcoal tray assembly
Charcoal rack
Cast iron flat top grill
Control button
Flame Tamer
Rear infrared
burner
3. Tegninger for montering
Trinn 1
Bruk 6 selvskruende skruer til å feste den venstre dekselstrimmelen på venstre
grillen og deretter gjenta denne prosedyren med høyre
Heating grill
Lid handle
Control button:
side burner
Right cover
Self-tapping screws 6x
Left cover
Cast iron grill Lid
Electric ignition
Right cover strip
Side burner
Cover strip backside
Charcoal tray assembly
Charcoal rack
Cast iron flat top grill
Control button
Flame Tamer
Rear infrared
burner
