BORETTI IBRIDO TOP - 3. Assembly drawings

9
ENBoretti Ibrido Top / User guide - Installation advice
Heating grill
Lid handle
Control button:
side burner
Right cover
Self-tapping screws 6x
Left cover
Cast iron grill Lid
Electric ignition
Right cover strip
Side burner
Cover strip backside
Charcoal tray assembly
Charcoal rack
Cast iron flat top grill
Control button
Flame Tamer
Rear infrared
burner
3. Assembly drawings
Step 1
Use 6 self-tapping screws to attach the left cover strip to the left side of the
barbecue and repeat this procedure to attach the right cover strip.
Heating grill
Lid handle
Control button:
side burner
Right cover
Self-tapping screws 6x
Left cover
Cast iron grill Lid
Electric ignition
Right cover strip
Side burner
Cover strip backside
Charcoal tray assembly
Charcoal rack
Cast iron flat top grill
Control button
Flame Tamer
Rear infrared
burner
