ENBoretti Maggiore / User guide - Installation advice
Step 3 - a) Place the control ring provided onto the side burner and tighten with the
M4 screw supplied.
b) Place the second M4 screw and tighten it, ensuring that the ‘H’ is pointing
to the ignition opening (left hand side).
Control ring
Side burner
M4 screw
Step 4 - a) Install the side burner with the 2x M4 screw. Return the pan stand into
position.
b) Install the control button and ensure that the flat side of the button
corresponds with the flat side of the gas valve.
Control buon
Pan stand
Side burner
