Page 13
4. Place the device in a suitable place, slightly tilting the smoking
unit, insert the legs into the slots on the bottom and adjust
them so that the device reaches the level.
5. Insert the protruding heating element of the smoke generator
into the side hole on the left side of the smoker. Tilt the
generator slightly to put it on the latches.
6. Insert the chimney into the hole at the top of the smoker. Pay
attention to the correct position of the throttle valve.
7. Insert the condenser under the chimney.
8. Insert the drip tray onto the bottom rack.
9. Mount the electronic control panel - see the description p. 14.
