Borofone Technology Co.,Ltd
catalog
1 overview…………………………………………………………第 2 页
2 battery status………………………………………………………第 3 页
3 Productfunction and process description…………………………第 4 页
4 performance parameter……………………………………………第 5 页
5 product appearance ………………………………………………第 6 页
1 overview
This specification describes the range of wireless charging and
transmitting applications produced by shenzhen meishiqi technology co.,
LTD,technological standard,Electrical Characteristics,Main material, The
main ingredient in,dimensions,Testing standards and other related items。
This specification can be used as the quality inspection standard and basis
of this product。
2 product function
2.1 W23 The wireless charging source board provides power to the
built-in circuit through MICRO interface input。
2.2 Working through the built-in conversion circuit through the wireless transmitter coil output，It
