Bort Alligator X - Installation: Disconnection, Disassembly, and Mounting; Installation: Drain Pipe and Dishwasher Connections

13
9. Installation gasket / protective reector
10. Eyelets
11. Lower mounting ring
12. Drain the dishwasher
13. Outlet opening Drainage system
14. Mounting Screws
15. Rubber gasket
16. Flange
17. Drain pipe with a knee
2. DISCONNECTION OF THE DROP HORN AT
TENTION!
At the time of installation of the device is
recommended Wear safety glasses. Loosen the nut
on the top of the water trap with a pipe wrench.
relative humidity not more than 80%. Loosen the
nut on the top of the extension pipe. Remove the
extension pipe.
Loosen the nut at the bottom of the washing
ange.
Push the washing ange upwards through drain
hole of the sink and remove it.
CLEAN THE WASH FAN WRAPPING PLACE FROM
THE SEALANT OR THE GARBAGE.
NOTE: It may be necessary to expand the drain
hole for installation ange fastening disposer.
Equipment for extending the drainage hole is
purchased separately.
3. DISASSEMBLY OF THE ASSEMBLY UNIT
• Turn over the assembly and loosen the three
xing screws (1) The access to the ring (2).
• Disconnect the retaining ring from the ange
with a screwdriver. Now the assembly unit can be
disassembled.
4. ATTACHING THE FIXING ASSEMBLY TO WASH-
ING Fig.5.1.
ATTENTION! To install the disposer, the thickness
of the sink in the area of the drain hole should be
no more than 18 mm.
1. Install one or two rubber gaskets (2) under the
washing ange (1). Make sure that The drainage
hole is not clogged, and set to ange washer /
gasket. In order to The ange of the sink became
in place, you need to crush it with a heavy load. (To
avoid scratches, use a towel as a lining.)
2. Put the second rubber part on the bottom of
the kitchen sink a gasket (2), a cardboard gasket
(optional) (3) and a metal support ring (4) (at side
up).
3. While holding the second rubber gasket,
cardboard padding (optional) and a metal support
ring, put the mounting ring (5) on the ange of the
sink so that it aligned with the support ring.
4. Pressing tightly to the bottom of the sink
rubber gasket, cardboard gasket, support ring and
mounting ring, slide the snap ring (7) onto the
ange of the sink so that it snaps into the ange
groove.
5. Tighten the three xing screws (6) to The xing
assembly was tight and evenly pressed to the sink.
5. CLEANING THE DRAIN PIPE
If you do not clean the drain pipe, it can clog.
1. Remove the water trap.
2. Using a cleaner, remove all solid precipitation in
the horizontal part of the drainage pipes, moving
with side of the siphon towards the main pipe.
IF THE DISHWASHER WILL NOT BE CONNECTED TO
THE DISPOSER, GO TO PART 7 OF THIS INSTRUCTION
6. CONNECTING THE DISHWASHER MACHINES
AND TRANSFER CONNECTION
If the sink is full of liquid it can be discharged into
the disposer through the inlet in its upper parts.
On all models inside the intake pipe there is
partition. The partition must be removed.
7. CONNECTING THE DISPOSER TO THE FIXING
UNIT ATTENTION!
To avoid injury, follow the so that during the
removal and installation of a part Your body was
not under the disposer; during the installation it is
possible to drop it.
Remove any objects from the grinding chamber
product before installing it on the sink.
1. Install the product in such a way that provide
easy access to the restart button engine located in
the lower part of the body. Do not block this place
with any objects.
2. Place the disposer with three mounting loops (1)
into the sliding position by mounting rails (2).
3. Lift the disposer, insert the top end (installation
