English–9
0 276 001 YYY | (12.10.12) Bosch eBike Systems
Technical Data
Assembly
Place down the battery pack only on clean surfaces. In
particular, avoid soiling the charge socket and the con-
tacts, e. g. by means of sand or ground.
Checking the Battery Pack Before Using for the
First Time
Check the battery pack before charging it or using it with your
eBike for the first time.
For this, press the On/Off button 22 to switch on the battery
pack. When no LED of the charge-control indicator 21 lights
up, the battery pack may be damaged.
When at least one, but not all LEDs of the charge-control indi-
cator 21 is lit, then fully charge the battery pack before using
for the first time.
Do not charge a damaged battery pack and do not use
it.
Please refer to an auth
orised bicycle dealer.
Charging the Battery Pack
Use only the charger provided with your eBike or an
identical original Bosch charger. Only this charger is
matched to the lithium-ion battery pack used in your eBike.
Note: The battery pack is supplied partially charged. To en-
sure full battery pack capacity, completely charge the battery
pack in the charger before using for the first time.
The battery pack must be removed from the eBike for charg-
ing.
For charging the battery pack, read and observe the operating
instructions of the charger.
The battery pack can be char
ged any time with
out reducing
the service life. Interrupting the charging procedure does not
cause damage to the battery pack.
The battery pack is equipped with a temperature control indi-
cator, which enables charging only within a temperature
range between 0°C and 40 °C.
When the battery pack is not
within the charging-tempera-
ture range, three LEDs of the
charge-control indicator 21
flash. Disconnect the battery pack from the char
ger
until its
temperature has adjusted.
Do not connect the battery pack to the charger until it has
reach the allowable charging temperature.
Charge-control Indicator
When the battery pack is switched on, the five green LEDs of
the charge-control indicator 21 indicate the charge condition
of the battery pack.
In this, each LED indicates approx. 20
%
capacity. When the
battery pack is completely charged, all five LEDs light up.
Additionally, the charge condition of the switched on battery
pack is indicated on the drive HMI. Read and observe the op-
erating instructions of the drive unit and the drive HMI.
When the capacity
of th
e battery pack is below 5 %, all LEDs
of charge-control indicator 21 on the battery pack go out;
however, the drive HMI does provide an additional indication
function.
Inserting and Removing the Battery Pack
(see figures C–D)
Always switch the battery pack off when inserting or
removing it from the holder.
In order for the battery pack to be inserted, the key 23 must
be inserted into the lock 24 and the lock must be unlocked.
To insert the standard battery pack 26, place it via the con-
tacts onto the bottom holder 27 on the eBike. Pivot the bat-
tery pack to the stop into the upper holder 25.
Lithium ion battery pack PowerPack 300 PowerPack 400
Article number
–Standard battery pack, black
–Standard battery pack, white
– Rack-type battery pack
0 275 007 500
0 275 007 501
0 275 007 502
0 275 007 503
0 275 007 504
0 275 007 505
Rated voltage
V=3636
Rated capacity
Ah 8.2 11
Energy
Wh 300 400
Operating temperature
°C –10...+40 –10...+40
Storage temperature
°C –10...+60 –10...+60
Allowable charging temperature range
°C 0...+40 0...+40
Weight, approx.
kg 2.5 2.5
Degree of protection
IP 54 (dust and splash water
protected)
IP 54 (dust and splash water
protected)
OBJ_BUCH-1407-003.book Page 9 Friday, October 12, 2012 1:01 PM
