14 | English
1 609 92A 4MR | (26.09.2018) Bosch Power Tools
u Do not operate the power tool when stationary . It is
not suitable for operation with a saw table.
u When performing plunge cuts which are not right-
angled, secure the guide plate of the saw so that it will
not shift sideways.In the event of a sideways shift, the
saw blade may become jammed, which could lead to kick-
back.
u Do not use HSS saw blades. Such saw blades can easily
break.
u Do not saw any ferrous metals. Hot chips may ignite the
dust extractor.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
u Always wait until the power tool has come to a com-
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
u Hold the power tool firmly with both hands and make
sure you have a stable footing. The power tool can be
more securely guided with both hands.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for making straight cuts in wood
with and against the grain and mitre cuts in wood while rest-
ing firmly against the workpiece. With suitable saw blades,
you can also saw thin-walled non-ferrous metals, such as
profiles.
The power tool must not be used to cut ferrous metals.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
On/off switch
(2)
Lock-off button for on/off switch
(3)
Hex key
(4)
Auxiliary handle (insulated gripping surface)
(5)
Spindle lock button
(6)
Scale for mitre/bevel angles
(7)
Wing bolt for mitre/bevel angle preselection
(8)
Wing bolt for parallel guide
(9)
Viewing window for "Cut Control"
(10)
Parallel guide
(11)
Retracting blade guard
(12)
Adjusting lever for retracting blade guard
(13)
Base plate
(14)
Wing bolt for preselecting the cutting depth
(15)
Cutting depth scale
(16)
Chip ejector
(17)
Protective guard
(18)
Handle (insulated gripping surface)
(19)
Saw spindle
(20)
Clamping flange
(21)
Circular saw blade
(22)
Mounting flange
(23)
Clamping bolt with washer
(24)
Cut mark 45°
(25)
Cut mark 0°
(26)
Dust extraction hose
A)
(27)
Pair of screw clamps
A)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Hand-held circular saw PKS 40
Article number
3 603 CC5 0..
Rated power input W 850
Power output W 530
No-load speed rpm 5300
Max. cutting depth
– at a 0° mitre/bevel angle mm 40
– at a 45° mitre/bevel angle mm 26
Spindle lock ●
CutControl ●
Base plate dimensions mm 135 x 260
Max. saw blade diameter mm 130
Min. saw blade diameter mm 122
Max. base blade thickness mm 1.4
Max. tooth thickness/offset mm 2.7
Min. tooth thickness/offset mm 1.7
Locating bore mm 16
Weight according to
EPTA-Procedure 01:2014
kg 2.6
