131 1 611 110 C71 Label 9
134 2 910 110 116 Screw 89
135 1 614 431 031 Cable 10
137 2 916 699 130 Lock Washer 65
138 1 611 015 053 Gasket 79
141 1 610 290 066 Seal 77
142 1 610 290 069 Seal 77
143 1 614 601 021 Spring Ring 89
144 1 610 251 006 Washer 86
145 1 610 119 012 Retaining Ring 89
146 1 610 210 174 O-Ring 78
154 2 916 660 023 Retaining Ring 89
160 1 610 210 161 Ring 9
162 1 610 210 163 O-Ring 78
165 1 610 210 079 O-Ring 78
167 1 610 283 033 Seal 77
171 1 613 435 016 Screw {6} 89
172 1 613 435 013 Screw {4} 89
174 1 613 435 012 Screw {6} 89
175 2 912 401 018 Screw {2} 89
176 1 613 435 012 Screw {2}
177 1 603 435 051 Screw {2} 89
192 1 614 611 019 Spring 27
195 1 613 435 020 Screw {2} 89
198 1 618 900 001 Lever 64
200 1 610 284 000 Bellows 9
202 1 611 010 006 Hook {2} 9
203 1 610 322 009 Washer {2} 65
803 1 614 011 109 Armature Assembly AW
w/pos. 13, 14, 15, 95,
111, 112, 141, 145
808 1 611 104 999 Nameplate 9
811 1 617 014 135 Brush Set 26
817 1 614 652 004 Brush Spring {2} 27
818 2 910 011 082 Screw {2} 89
821 1 617 000 842 Bushing Assembly 82
w/pos. 121, 142, 167
835 1 617 000 433 Guide Tube Assembly 43
w/pos. 25
840 1 617 000 847 Gear Housing Assembly 72
w/pos. 95, 104, 141, 145
849 1 617 000 839 Fork Assembly 62
856 1 617 000 843 Piston Assembly 47
w/pos. 165
860 1 617 000 844 Clutch Assembly 67
873 1 617 000 861 Gear Housing Cover 70
w/pos. 138
884 1 612 025 055 Auxiliary Handle 9
w/pos. 84, 85, 86, 87
891 1 617 000 853 Shock Absorber 9
w/pos. 200
895 1 615 430 019 Oil 1
897 1 617 000 430 Service Pack 78
w/pos. 21, 25, 138, 143,
162, 165, 811
898 1 615 437 511 Oil w/pos. 138 1
1 1 615 102 155 Motor Housing 71
2 1 614 220 163 Field 22
4 1 617 200 094 Switch 15
w/pos. 818
5 1 614 461 035 Cord 11
6 1 610 703 056 Strain Relief 11
7 1 601 302 019 Clamp 89
9 1 611 110 C58 Label 9
13 1 610 900 026 Ball Bearing 60
14 1 610 905 028 Ball Bearing 61
15 1 616 610 090 Fan 23
21 1 610 508 038 Dust Shield 92
22 1 610 591 027 Sleeve 86
23 1 610 520 001 Stop Sleeve 86
25 1 612 300 036 Locking Cog {2} 86
26 1 610 290 076 Disc 86
27 1 610 591 028 Air Deflector 24
28 1 614 621 000 Spring 86
30 1 610 502 011 Disc 86
31 1 610 290 049 Bushing 82
34 1 610 516 013 Flange 9
37 1 615 500 315 Bracket 9
38 1 615 190 101 Cover 9
42 1 614 336 046 Bush Holder 25
w/pos. 811, 817
43 1 615 500 322 Cover 70
44 1 614 617 003 Spring 27
47 1 610 300 064 Sleeve 82
48 1 616 334 012 Sleeve 82
51 1 616 333 041 Gear 33
53 1 610 290 068 Washer 65
57 1 618 710 074 Striker 44
72 1 616 317 064 Eccentric Gear 34
74 1 611 921 001 Plate 9
75 1 615 132 087 Handle 74
79 1 613 435 015 Screw {2} 89
80 1 617 233 033 Speed Control 17
81 1 615 132 088 Handle Cover 74
84 1 612 025 054 Auxiliary Handle 9
85 1 618 040 074 Clamp Holder 80
86 1 613 490 001 T-Bolt 80
87 1 611 316 019 Clamping Band 80
94 1 610 102 056 Washer {2} 65
95 1 610 210 173 O-Ring 78
97 1 610 031 005 Washer 65
99 1 610 102 059 Washer 65
* 102 1 610 102 057 Shim 65
* 102 1 610 102 058 Shim 65
104 1 610 210 160 O-Ring 78
111 1 610 290 064 Bushing 82
112 1 613 300 008 Nut 89
113 1 613 435 009 Screw {2} 89
116 1 610 311 017 Bushing 82
117 1 610 913 004 Needle Bearing {2} 56
121 1 610 328 019 Bushing 82
124 1 610 115 001 Sleeve 82
126 2 910 211 019 Screw 89
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
11241EVS ROTARY HAMMER
