Model number 11245EVS
Shank style SDS Max
Maximum Capacities:
Carbide tipped bits
2”
Thin wall core bits 6”
Functional Description and Specifications
D
isconnect the plug from the power source before making any
assembly, adjustments or changing accessories.
Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Rotary Hammer
DUST SHIELD
LOCKING SLEEVE
VENTILATION OPENINGS
SELECTOR LEVER
TRIGGER
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
VENTILATION
OPENINGS
HAND GRIP
AUXILIARY
HANDLE
FIG. 1
RELEASE BUTTON
NOTE: For tool specifications refer to the nameplate on your tool.
