Model number 11316EVS
Shank style SDS Max
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
Demolition Hammer
LOCKING
SLEEVE
VENTILATION
OPENINGS
SLIDE
ON/OFF
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
HAND GRIP
AUXILIARY
H
ANDLE
D
UST
S
HIELD
VARIO-LOCK
SELECTOR
RING
FIG. 1
NOTE: For tool specifications refer to the nameplate on your tool.
