-6-
Model number 11318EVS
Shank style
SDS Max
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories.
Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Demolition Hammer
DUST SHIELD
LOCKING SLEEVE
TRIGGER
SWITCH
TRIGGER
RELEASE
SWITCH
HAND GRIP
AUXILIARY
HANDLE
NOTE: For tool specifications refer to the nameplate on your tool.
FIG. 1
VARIO-LOCK
SELECTOR
RING
VARIABLE SPEED DIAL
SERVICE REMINDER LIGHT
POWER INDICATOR LIGHT
VENTILATION
OPENINGS
