Trim Router Components
1. Ventilation openings
2. Wrench slot
3. Slide "ON/OFF" switch
4. Motor clamping ring
5. Collet nut
6. Base assembly
7. Sub-base
8. Clamping ring screw
9. Trim guide assembly
10. Locking knob - depth of cut
11. Adjusting screw - depth of cut
12. Adjusting knob - trim guide
13. Locking screw - trim guide
14. Combination Wrench
15. Toothed Belt Pulley
16. Offset Base Assembly
17. Toothed Belt
18. Depth Locking Screw
19. Slotted Adjusting Gear
20. Wing Nuts
(NOTE: components not illustrated on page 2 are illustrated elsewhere in this manual)
1608M 1608 1608LX 1608T 1608U 1609A 1609AK
1609AKX
Steel Case * *
650 Watt Trim Motor * * * * * * * *
Wrench 2pcs 2pcs 2pcs 2pcs 2pcs 1pc 2pcs 2pcs
Trimmer Base * * * *
Laminate Trim Guide *
Deluxe Laminate * *
Trim Guide
Tilt Base * * *
Offset Base * * *
Underscribe Base * *
4mm Hex Key * * * *
3mm Hex Key * *
1/4 Collet * * * * * * *
Collet Nut * * * * * * *
Carbide Tipped Bit * *
Toothed Belt Pulley * * *
Product Data - Trim Router
Base dimensions 3.7" x 2.8" (95mm x 71mm)
Collet capacity 1/4" max.
Bit diameter 1" max.
(NOTE: This tool is designed for use with alternating current (AC) only.)
Accessory Listing
*STANDARD EQUIPMENT—ALL MODELS
BM 2610909755 7/01 7/26/01, 12:03 PM3
