3
Product Data - Plunge Router
Model number 1613 1613EVS.
Identification number 0 601 613 0 . . 0 601 613 7 .
Router bit capacity 1-5/8" dia. max. 1-5/8" dia. max.
Collet capacity 1/4", 3/8", & 1/2" shanks 1/4", 3/8", & 1/2" shanks
Model number 1614 1614EVS.
Identification number 0 601 614 0 . . 0 601 614 7 .
Router bit capacity 1-5/8" dia. max. 1-5/8" dia. max.
Collet capacity 1/4" shank 1/4" shank
NOTE: This tool is designed for use with alternating current (AC) only.)
Accessory Listing
1613 & 1613EVS 1614 & 1614EVS
1/4" Collet chuck* 1/4" Collet chuck*
3/8" Collet chuck 3/4" Collet wrench*
1/2" Collet chuck* Deluxe router guide
15/16" Collet wrench* Vacuum attachment
Deluxe router guide Vacuum hose
Vacuum attachment Hose/vacuum adaptor
Vacuum hose Carrying case
Hose/vacuum adaptor
Carrying case
(* = standard equipment)
Router Components
1. Fine adjust knob 14. Chip deflector
2. Variable speed dial (1613EVS & 1614EVS) 15. Subbase
3. Depth indicator rod 16. Plunge lock/release lever
4. Depth indicator 17. Index marker
5. Depth indicator lock/release knob 18. Trigger switch
6. Templet guide lock/release lever 19. Vacuum attachment
7. Revolving depth turret 20. Vacuum hose
8. "Lock-ON" button 21. Retaining ring
9. Router guide adustment knob 22. Collet
10. Deluxe router guide 23. Collet nut
11. Spindle lock 24. Templet guide
12. Guide plate 25. Collet chuck assembly
13. Guide plate 26. Router bit
27. Template pattern
(NOTE: Router components not illustrated on page 2 are illustrated elsewhere in this manual)
BM 2610967928 1/97 12/7/98, 10:29 AM3
