-8-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
FIG. 1
SPEED CONTROL DIAL
Models 1617EVS
& 1618EVS only
SUB-BASE
TRIGGER
SWITCH
"LOCK-ON"
BUTTON
D-HANDLE
ROUND
HANDLE
BASE CLAMP LEVER
CHIP DEFLECTOR
MOTOR HOUSING
ROCKER ON\OFF
SWITCH
POWER ON/OFF
SWITCH
TEMPLET GUIDE
QUICK CHANGE LEVER
(Not included, available as
accessory)
MOTOR ALIGNMENT
ARROW
FIG. 2
AIR VENTS
AIR VENTS
REVERSIBLE
HANDLE
BIT ROTATION ARROW
BIT ROTATION ARROW
Routers
BASE TYPE S
BASE TYPE D
1617EVS
1618EVS
SPEED CONTROL DIAL
Models 1617EVS
& 1618EVS only
TEMPLET GUIDE
QUICK CHANGE LEVER
(Not included, available as accessory)
