Bosch 16176 - Electronic Variable Speed Router Motor User Manual

-9-
2
1
0
IN
50
40
30
20
10
0
MM
FIG. 3
SPEED CONTROL DIAL
Model 1617EVSP only
SUB-BASE
PLUNGE HANDLE
CHIP DEFLECTOR
MOTOR HOUSING
ROCKER ON\OFF SWITCH
MOTOR
ALIGNMENT ARROW
AIR VENTS
BIT ROTATION ARROW
BASE TYPE P
Collet capacities 1/4", 3/8", 1/2", 8mm
NOTE: For tool specifications refer to the nameplate on your tool.
RA1161 fixed-base shop router base marked type "S" is designed for use with these router motors:
1617 router motor (16171)
1617EVS router motor (16176)
1618EVS router motor (16186)
RA1162 D-handle router base marked type "D" is designed only for use with these router motors:
1618EVS router motor (16186)
RA1166 plunge router base marked type "P" is designed for use with these router motors:
1617 router motor (16171)
1617EVS router motor (16176)
1618EVS router motor (16186)
PLUNGE LOCK
LEVER
DEPTH ROD
DEPTH ROD KNOB
DEPTH STOP TURRET
DEPTH INDICATOR
DEPTH ROD FINE
ADJUSMENT KNOB
1617EVSPK
