-17-
(* = standard equipment)
(** = optional accessories)
* Screwdriver bit
* Carrying case
Accessories
If an extension cord is
necessary, a cord with
adequate size conductors that is capable of
carrying the current necessary for your tool
must be used.
This will prevent excessive
voltage drop, loss of power or overheating.
Grounded tools must use 3-wire extension
cords that have 3-prong plugs and
receptacles.
NOTE: The smaller the gauge number, the
heavier the cord.
RECOMMENDED SIZES OF EXTENSION CORDS
120 VOLT ALTERNATING CURRENT TOOLS
!
WARNING
Tool’s
A
mpere
R
ating
Cord Size in A.W.G.
Wire Sizes in mm
2
3-6
6
-8
8
-10
10-12
1
2-16
18 16 16 14 0.75 0.75 1.5 2.5
1
8 16 14 12 0.75 1.0 2.5 4.0
18 16 14 12 0.75 1.0 2.5 4.0
16 16 14 12 1.0 2.5 4.0 —
1
412—— ————
25 50 100 150 15 30 60 120
Cord Length in Feet
C
ord Length in Meters
Extension Cords
