2000 Series |
Program Entry Guide | 2.0
Phone
EN
| 10
Bosch Security Systems | 7/05 | 35114F
15 Test Route
Default:
Local
Selection:
Local, Phone 1 only, Phone 2 only,
Both
Local 0
Phone 1 only
1
Phone 2 only
2
Both 3
Reports:
•
Test Reports
•
Service Start (stand-by pin locked down, installer
code entered.)
•
Service Stop (standby-by pin unlocked. The
control panel only sends a Service Stop Report
if a Service Start Report was transmitted).
9
11
Table of Contents
Default Chapter
2
About this Manual
2
Table of Contents
3
1 System Configuration
5
2 Phone
7
Phone Routing Set to no
7
Phone Routing Set to Yes
7
Table 1: Phone Routing Set to no
7
3 Reports
11
4 Receiver
15
Modem Reports
15
Table 2: Modem II Reports Chart
15
Pulse Report Groups
18
Figure 1: Pulse Report Groups
18
Table 3: Pulse Format
18
5 Remote Programming
21
Table 4: Answer Machine Programmed Yes
22
6 Open/Close
23
Step Outside
24
Exit
25
7 ABC Keys
27
8 Bell
29
9 Test Timer
31
10 Address Configuration
33
11 Point Codes
35
Alarm Report Delay)
35
Digit 1, Point Type
37
Table 5: Digit 1 Selections
37
Digit 2, Alarm Responses
43
Table 6: Digit 2 Selections
43
Digit 3, Point Options
44
Table 7: Digit 3 Selections
44
Digit 4, Device Address
45
Table 8: Digit 4 Selections
45
Digit 5, Sensor Loop
46
Output
47
Table 9: Digit Selection Summary
47
Recommended Point Codes
48
Alarm Output, Alarm Report Delay)
48
Table 10: Smoke Detector (Trouble on Open, Alarm Output)
48
Table 11: Door with Entry/Exit Delay
48
Table 12: Door or Window with no Entry/Exit Delay
48
Table 13: Garage Door with Extended Entry/Exit Delay
48
Table 14: Motion Detector
48
Table 15: Tamper (Swinger Bypass, Alarm Output, Alarm Report Delay)
48
Table 16: Panic Device (Swinger Bypass)
49
Table 17: Keyswitch
49
12 Point Text
51
13 Relays
53
Relay Function Logic
53
Relay Functions
53
Table 18: Relay Function Selections
54
Relay Parameters, for Keypad Programming
56
Only
56
Table 19: Relay Parameters
56
14 User Test
57
15 Passcodes
59
16 RF Parameters
61
17 Program Lock
63
18 Keypad Programming
65
Getting Started
65
View Mode
65
Figure 2: View Mode
65
Table 20: View Mode Keys
65
Modify Mode
66
Scroll Lists
66
Yes and no Entries
66
Figure 3: Modify Mode
66
Table 21: Modify Mode Keys
66
An Example, Entering Custom Text
67
Table 22: Entering Custom Text at the Keypad
67
Keypad Programming Tips
68
Index
69
