English - 4
Stop, remove plug from the power supply
and remove the grassbox.
Note: To ensure long and reliable service, carry out
the following maintenance regularly.
Regularly check for obvious defects such as loose,
dislodged or damaged tines, loose fixings, and worn
or damaged components.
Check that covers and guards are undamaged and
correctly fitted. Carry out necessary maintenance or
repairs before using.
If the raker should happen to fail despite the care
taken in manufacture and testing, repair should be
carried out by an authorised customer service agent
for Bosch garden products.
For all correspondence and spare parts orders, al-
ways include the 10-digit part number from the
nameplate of the machine!
Stop, remove plug from the power supply
and remove the grassbox.
– turn the machine upside down
– remove the tine cover by removing screws 12
– remove the broken/damage tine 13 and fit re-
placement tine
– re-fit the tine cover and screws 12
Clean the exterior of the machine thoroughly using a
soft brush and cloth. Do not use water, solvents or
polishes. Remove all grass and debris, especially
from the ventilation slots 8.
Turn the machine on its side and clean the tine area.
If grass cuttings are compacted in the tine area, re-
move with a wooden or plastic implement.
Store the lawnraker in a dry place. Do not place
other objects on top of the machine. To save space,
fold up the handle fully.
☞
Ensure cables are not trapped when
folding/unfolding top handles, do not drop
the handles.
The following table gives checks and actions that you can perform if your machine does not operate correctly.
If these do not identify/remedy the problem, contact your service agent.
Warning: Switch off and remove plug from mains before investigating fault.
Maintenance Removing/Fitting Raker tine
After Raking or
Scarifying Storage
G
H
Fault Finding
Symptom Possible Cause Remedy
Machine fails to operate Power turned off
Mains socket faulty
Extension cable damaged
Fuse faulty/blown
Turn power on
Use another socket
Inspect cable, replace if damaged
Replace fuse
Machine functions
intermittently
Extension cable damaged
Machines internal wiring damaged
worn/missing tines
Inspect cable, replace if damaged
Contact Service Agent
fit replacment
Machine labours or belt
squeals
Raking/Scarifing too low Increase height of raking
see “Adjusting the operating height”
Cutting tines not rotating Cutting tines obstructed by gras
Belt is slipping or is damaged
Clear obstruction
Contact Service Agent
Excessive
vibration/noise
Cutting tines damaged Contact Service Agent
Poor collection Raking/scarifing in wet conditions see “Adjusting the operating height”
