Bosch ARM 32 - Mounting and Operation; Delivery Scope and Assembly; Starting and Operating Procedures; Troubleshooting

6 | English
F 016 L81 451 | (13.1.16) Bosch Power Tools
Mounting and Operation
Troubleshooting
Action Figure
Delivery Scope 1
Handle Assembly 2
Snap together the Grassbox 3
Grassbox fitting/removing 3
Adjusting the Cutting Height 4
Connecting the Extension Lead 5
Starting 5
Stopping 5
Working Advice 5 – 6
Blade Maintenance 7
Selecting Accessories 7
Action Figure
STOP
Problem Possible Cause Corrective Action
Motor refuses to start Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Possible clogging Check underneath the garden product and
clear out as necessary (always wear gardening
gloves)
Motor protector has activated Allow motor to cool and increase height of cut
Mowing too low for the conditions Increase height of cut
Machine functions
intermittently
Extension cable damaged Inspect cable, replace if damaged
Internal wiring of garden product damaged Contact Service Agent
Motor protector has activated Allow motor to cool and increase height of cut
Garden product leaves ragged
finish
and/or
Motor labours
Height of cut too low Increase height of cut
Cutting blade blunt Replace the blade
Possible clogging Check underneath the garden product and
clear out as necessary (always wear gardening
gloves)
Blade fitted upside down Refit blade correctly
Blade not rotating while garden
product switched on
Cutting blade obstructed Switch off garden product
Clear obstruction (always wear gardening
gloves)
Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Excessive vibrations/noise Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Cutting blade damaged Replace the blade
