FAQs
Test Menu
Notification Test
Revisions
Test Report
Walk Test
RFBT
Billtrap
Transmitter
RFDL–11
PIR Microwave
TriTech
35 x 25 ft.
RFPR–12
PIR, Pet
Immune
40 ft.
RFDW–RM
Recessed Door/
Window Contact
RFDW–SM
Surface Mount
Door/Window
Contact
RFGB
Glass
Break
Detector
RFUN Universal
Transmitter w/
Door/Window
Contact
RFSM
Wireless
Smoke
Detector
RFPR–C12
Curtain PIR,
Pet Immune
40 x 5 ft.
RFPB–SB
RFPB–TB
1 & 2 Button
Panic
RFKF–TBS
RFKF–FBS
2 & 4 Button
Keyfobs
ACA–ATR13 ACD–ATR14CSACD–ATR11ISO
B810 SDI2 Wireless Receiver
RFRP Wireless Repeater
Any Bosch IP camera
DS9370/
DS9371
360
TriTech
70 ft.
ISC–BDL2–WP12G/
WP6G/W12G TriTech
40 X 40 ft./20 x 20
ft./ 40 x 40 ft.
B430 Telephone
(PSTN)
D192G Bell Super
Vision Module
D125B Dual Class B
Initiating Module
B201 2–wire
powered loop
F220/F220–B6R
Smoke Detector
plus Base
D132A
Reversing Relay
B56 Keypad
Backbox
D137
Mounting
Bracket
D138
Mounting
Bracket
Right Angle
ICP–EZTS
Universal
Tamper
B10 Medium
Enclosure
B11 Small
Enclosure
B208 Octo-
Input Module
B308 Octo-
Output Module
ISC–CDL1–W15x
TriTech
50 ft.
Commercial Series
B443 Cellular (HSPA+
SIM Required)
D5500CU
RPS Upgrade
Remote Security
Control
Mobile App
B99
USB Cable
Remote Security Plus
Mobile App
G450 Z-Wave
Home Control Gateway
EN4200
Serial Receiver
B820
Wireless Interface
B942W
Touch Screen
What is my default code?
User Code: 123456
Installer Code: 123
How do I use Output B and C?
Outputs B and C are Open Collector Outputs. Wiring can be
found in control panel installation manual, section heading Open
Collector Outputs.
How do you remotely turn on and turn off the control panel?
This can be done through the use of the Remote Security Control
App.
How do I connect directly to the control panel with Ethernet?
By default, the control panel is set up to auto detect and negotiate
a connection to RPS when an ethernet cable is connected between
them.
What do I need to be able to send personal notications?
SMS (Text) messages require the use of a cellular module and
emails can be sent by either an Ethernet or Cellular connection.
How do I enter “Service Mode”?
Press and hold the yellow reset button on the control panel for 5
seconds (repeat to exit).
Control panel
B901 Access Module
(B6512 only)
(B942 is keypad shown)
D101 Lock and
Key set
ISC–CDL1–WA15x
TriTech+ w/Anti-Mask
50 ft.
Note: Not all products and features are available in all regions. Consult your Bosch representative or product datasheets for details.
*Home automation may not be available in all regions.
Consult your Bosch representative for details.
-A versions of RADION devices are used in North and South America.
Non -A versions are used in Europe, Africa, and Australia.
B442 Cellular
(GPRS SIM Required)
B444 Cellular
(Verizon LTE, hot
SIM Required)
B Series Control Panel
Installer Quick Start Guide
Step 11a
Bosch tips:
Step 12
After system installation and control panel programming, you
must perform a complete system test. A complete system test
includes testing the control panel, all devices, and communication
destinations for proper operation.
Test the system
Bosch tips:
B Series control panel accessories (partial list)
FAQs
Where can I go for additional information?
B520 AUX Power Supply
*CX4010
18 VAC
Transformer
*TR1850
18 VAC
Transformer
D1218
18Ah Battery
D135A Low-Battery
Disconnect Module
D126
7Ah Battery
Power Communicators
RADION wireless devices
Keypads
B940W
Touch Screen
B920 Text w/
Function Keys
B930 Text w/
Soft Keys
B915 Text
B921C
Capacitive Touch
RFID tags (for Readers & B942 Keypads)
Inovonics wireless devices
Programing and software
IP camera integration
Enclosures & accessories
Residential re
Access
modules
I/O expansion modules
*Home automation
Wired motion detectors
Blue Line Gen2 Series Classic Series
Step 10
Bosch tips:
Congure and send to control panel using RPS
▶ Program your conguration information using Account Assistant.
1. Press close Account Assistant, and connect to control panel. This
opens the Panel Communication window.
2. Press Connect and send conguration programming to control panel.
Accessing the Installer Service Portal
and create panel account
Using the Installer Services Portal:
▶ Before you can use Installer Services Portal you must register for
services at: https://sp.boschsecurity.com.
▶ Make sure the control panel is connected to the network.
1. Log into the Installer Services Portal.
2. Click on New and select Device to create a panel account.
3. Add panel account information.
4. Activate CloudID. ISP searches database for registered ID.
5. Select Activate.
6. Click Add Panel.
3. Press Disconnect from control panel when
programming is complete. Go to Step 12.
*DE-45-18
18 VAC Transformer
*Country specic, variants will apply
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions)
Step 11b
▶ Search or select device to connect to a control panel. Type in panel
account name in the Search eld to locate new account.
Bosch tips:
Connect and send using the Installer
Service Portal
Using the Installer Services Portal:
B450 Remote Cellular Interface
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions)
(Not in all regions)
Installer Services
Portal
(Not in all regions)
▶ Perform a Walk Test
1. Select Actions.
2. Select Test.
3. Select Walk Test.
4. Choose a test to run.
▶ Send a test report
1. Select the panel account.
2. Click Connect.
3. Click Conguration. Program your
conguration information.
4. Click the 3 vertical dots and select
Push Pending Changes to Panel to
send conguration.
5. Click Disconnect when
conguration is complete.
© Bosch Security Systems B.V., 2019 Modications reserved F.01U.324.620 | 04 | 2019.09
www.boschsecurity.com
B942
Touch Screen
B444-V Cellular
(Verizon LTE)
B444-A Cellular
(AT&T LTE)
(Not in all regions)
Bosch Security Systems B.V.
Torenallee 49
5617 BA Eindhoven
Netherlands
B915I Text
(Not in all regions)
