2 THEMES VON A – Z
2.1 Condensation tray flows over
Condensation trays can overflow without visible mechanical failure
(loose or defect door gasket, etc.).
Solution:
In this case a self-adjusting heater has to be installed. This heater
assists the evaporation at a high water-level.
Spare part-No.: 00753407
The assembly has to be done according to the spare part information.
Please be sure that the heater is connected parallel to the power
supply.
Function:
If water completely surrounds the heater, the temperature and the
resistance decrease.  Heater heats
If no water surrounds the heater, the temperature and the resistance
increase.  heater stopps heating
Overview heater
Temperature in ºC
resistance in KΩ tolerance +/-30%
20 ºC
1,7 KΩ
30 ºC
2,3 KΩ
40 ºC
3,4 KΩ
50 ºC
6,2 KΩ
60 ºC
20,5 KΩ
