Bosch B926F User Manual

Fire status indicators
In conjunction with the display and status indicators,
the fire keypad includes Fire status indicators.
The indicator lights when a fire alarm condition exists.
The indicator lights when a user silenced a fire alarm condition.
The indicator lights when a supervisory point is not normal.
The indicator lights when there is a trouble condition
Certifications and approvals
Region Regulatory compliance/quality marks
USA ANSI-
SIA
CP-01-2010-Control Panel Standard -
Features for False Alarm Reduction
UL UL 365 - Police Station Connected Bur-
glar Alarm Units
UL UL 609 - Standard for Local Burglar
Alarm Units and Systems
UL UL 636 - Holdup Alarm Units and Sys-
tems
UL UL 864 - Standard for Control Units and
Accessories for Fire Alarm Systems
UL UL 985 - Household Fire Warning Sys-
tem Units
UL UL 1023 - Household Burglar Alarm Sys-
tem Units
UL UL 1076 - Proprietary Burglar Alarm
Units and Systems
UL UL 1610 - Central Station Burglar Alarm
Units
UL [B9512G, B9512G-E, B8512G,
B8512G-E, B299, B600, B901, B925F,
B926F]
UL UL 294 - Standard for Access Control
Units and Systems
UL UL 1635 - Standard for Digital Alarm
Communicator System Units
CSFM California Office of The State Fire Mar-
shall
Canada ULC CAN/ULC S303 - Local Burglar Alarm
Units and Systems
ULC CAN/ULC S304 - Standard for Signal Re-
ceiving Center and Premise Burglar
Alarm
ULC CAN/ULC S545 - Residential Fire Warn-
ing System Control Units
ULC ULC-ORD C1023 - Household Burglar
Alarm System Units
ULC ULC-ORD C1076 - Proprietary Burglar
Alarm Units and Systems
Region Regulatory compliance/quality marks
ULC [B9512G, B9512G-E, B8512G,
B8512G-E, B299, B600, B901, B925F,
B926F]
IC ICES-003 - Information Technology
Equipment (ITE)
Installation/configuration notes
Mounting considerations
Mount in indoor, dry locations.
Power supply
A compatible control panel supplies the power and
data requirements to the keypad through a four-wire
connection.
Enclosure and wiring
The sliding self-locking enclosure has an integrated
bubble level and custom gap-free, lift-gate style
terminal blocks to make installation easier.
Compatible control panels
B9512G/B9512G-E
B8512G/B8512G-E
Parts included
Quan
tity
Component
1 Keypad
1 Hardware pack
1 Installation Guide
1 User’s Quick Reference Guide
Technical specifications
Power requirements
Current Standby: 35 mA
Alarm: 70 mA
Voltage (input) 12 VDC nominal
Materials and hardware features
Dimensions 158 mm x 120 mm x 26 mm (6.2 in x
4.7 in x 1 in)
Weight 0.32 kg (11.3 oz)
Material Acrylonitrile butadiene styrene (ABS)
Poly(methyl methacrylate) (PMMA)
Display window 2 line display
18 characters per line
Indicators Illuminated keys
Status indicators
Warning and indicating tones
2 | B926F Fire keypad, SDI2

Bosch B926F Specifications

General

Connectivity technology	Wireless
Operating temperature (T-T)	0 - 49 °C
Operating relative humidity (H-H)	5 - 93 %

Weight and Dimensions

Depth	120 mm
Width	158 mm
Height	26 mm
Weight	320 g
