English–2
0 275 007 XCX | (28.6.17) Bosch eBike Systems
Technical Data
Operation
Initial Operation
Connecting the charger to the mains (see figure A)
Observe the mains voltage! The voltage of the power
supply must correspond with the data given on the name-
plate of the battery charger. Battery chargers marked with
230 V can also be operated with 220 V.
Plug the charger plug 3 of the power cord into the charger
socket 2 of the charger.
Connect the mains cable (country-specific) to the mains
supply.
Charging the removed battery (see figure B)
Switch the battery pack off and remove it from the holder of
the eBike. For this, read and observe the operating instruc-
tions of the battery pack.
Place down the battery pack only on clean surfaces. In
particular, avoid soiling the charge socket and the con-
tacts, e.g. by means of sand or soil.
Insert the charger plug 5 of the battery charger into the socket
6 on the battery pack.
Charging the battery on the Bike (see figures C and D)
Switch the battery off. Clean the cover of the charge socket 7.
Prevent especially the charge socket and the contacts from
getting dirty, e.g. by sand or soil. Lift the cover of the charge
socket 7 and plug the charge connector 5 into the charge
socket 6.
Charge the battery only in accordance with all safety
instructions. If this is not possible, remove the battery
from the holder and charge it in a more suitable location.
When doing so, read and observe the operating instruc-
tions of the battery.
Battery Charger Standard Charger
(36–4/230)
Standard Charger
(36–4/100-230)
Compact Charger
(36–2/100-240)
Article number
0 275 007 907 0 275 007 923 0 275 007 915
Rated voltage
V~ 207...264 90...264 90...264
Frequency
Hz 47...63 47...63 47...63
Output voltage
V3636 36
Charging current (max.)
A442
Charging time
– PowerPack 300 approx.
– PowerPack 400 approx.
– PowerPack 500 approx.
h
h
h
2.5
3.5
4.5
2.5
3.5
4.5
5
6.5
7.5
Operating temperature
°C –5...+40 –5 ...+40 –5 ...+40
Storage temperature
°C –10...+50 –10 ...+50 –10 ...+50
Weight, approx.
kg 0.8 0.8 0.6
Degree of protection
IP 40 IP 40 IP 40
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Power cord Australia Japan
Article number
1 270 020 344 1 270 020 332
Rated voltage–Cable
V~ 300 300
Rated voltage–Connectors/plug-in connectors
V~ 250 125
Rated current – Connectors/plug-in connectors
A10/2.5 7
Material–Cable
PVC PVC
Safety standard–Cable
AS/NZS 3191 JIS C3304
Safety standard–Connectors/plug-in connectors
AS/NZS 3112
AS/NZS 3109
JIS C8303
Length, approx.
m1.51.5
