English – 9
ing) and no button is pressed on the on-board com-
puter or the control unit of the eBike, the eBike sys-
tem will switch off automatically.
Battery charge indicator
The battery charge indicator (3) displays the eBike
battery's state of charge. The state of charge of the
eBike battery can also be checked on the LEDs of the
battery itself.
In the(3) display, each ice-blue bar represents 20%
capacity and each white bar represents 10% capac-
ity. The topmost bar shows the maximum capacity.
Example: Four ice-blue bars and one white bar are
displayed. The state of charge is between 81% and
90%.
If capacity is low, both of the lower displays change
color:
Bar Capacity
2 × orange 30% to 21%
1 × orange 20% to 11%
1 × red 10% to reserve
1 × red flashing Reserve to empty
If the eBike battery is being charged, the topmost bar
on the battery charge indicator(3) flashes.
Setting the assistance level
On the control unit using the(8) and(9)buttons, you
can set how much the eBike drive assists you while
pedaling. The assistance level can be changed at any
time, even while cycling, and is displayed in color.
Level Color Notes
OFF
None Motor support is switched off. The
eBike can just be moved by pedal-
ing, as with a normal bicycle.
ECO
Green Effective support with maximum ef-
ficiency, for maximum range
TOUR
Blue Steady support, long range for tour-
ing
eMTB/
SPORT
Purple Optimal support whatever the ter-
rain, rapid acceleration when start-
Level Color Notes
ing from a standstill, improved dy-
namics and top performance
TURBO
Red Maximum support even at a high ca-
dence, for sport cycling
The designations and configuration of the assistance levels can
be preconfigured by the manufacturer and selected by the bicy-
cle retailer.
Interaction between the eBike system and
gear-shifting
The gear shifting should be used with an eBike drive
in the same way as with a normal bicycle (observe the
operating instructions of your eBike on this point).
Irrespective of the type of gear shifting, it is advisable
that you briefly reduce the pressure on the pedals
when changing gear. This will aid gear shifting and re-
duce wear on the powertrain.
By selecting the correct gear, you can increase your
speed and range while applying the same amount of
force.
Switching bike lights on/off
Before starting each journey, check that your bike
lights are working correctly.
To switch on the bike lights, press the (9)button for
more than 1s.
You can use the(11) and(10) buttons to control the
brightness of the LEDs on the control unit.
Switching the push assistance on/off
The push assistance aids you when pushing your
eBike. The speed of this function depends on the se-
lected gear and can reach a maximum of 3.7mph.
The lower the selected gear, the lower the speed of
the push assistance function (at full power).
u The push assistance function must only be used
when pushing the eBike. There is a risk of injury if
the wheels of the eBike are not in contact with the
ground while using the push assistance.
To start walk assistance, press the (8)button for
more than 1s and keep it pressed. The battery
Bosch eBike Systems 0 275 U07 3RL | (09.07.2021)
