Product description and specifications
LED Remote product features
All illustrations of bike parts except for the drive unit,
on-board computer including operating unit, speed
sensor and the corresponding holders are schematic
and may differ on your eBike.
(1)
(7)
(8)
(9)
(10)
(11)
(2)
(12)
(5)(4)(3)
(6)
(1)
On/off button
(2)
Select button
(3)
LEDs for battery charge indicator
(4)
ABS LED (optional)
(5)
Assistance level LED
(6)
Holder
(7)
Diagnostics connection (for servicing pur-
poses only)
(8) Button for decreasing support level –/
walk assistance
(9) Button for increasing support level +/
bike lights
(10)
Button to reduce brightness/
go back
(11)
Button to increase brightness/
go forward
(12)
Ambient light sensor
