Introduction
About Warnings
This manual contains many DANGER, WARNING,
and CAUTION indicators concerning the conse-
quences of failure to use, assemble, maintain, store,
inspect and dispose of a Bosch-equipped eBike in a
safe manner.
– The combination of the safety alert symbol and the
word DANGER indicates a hazardous situation that,
if not avoided, will result in death or serious injury.
– The combination of the safety alert symbol and the
word WARNING indicates a hazardous situation
that, if not avoided, could result in death or serious
injury.
– The combination of the safety alert symbol and the
word CAUTION indicates a hazardous situation
that, if not avoided, could result in minor or moder-
ate injury.
General Warnings
Read all safety warnings and all in-
structions. Failure to follow the warn-
ings and instructions may result in
death or serious injury.
Save all safety warnings and instructions for fu-
ture reference.
The term battery pack used in these operating in-
structions refers to all original Bosch eBike battery
packs.
WARNING
u This manual contains important safety, perfor-
mance and service information. Read it before
you take the first ride on your new bicycle, and
keep it for reference. The manual can also be found
online at www.bosch-ebike.com.
u This manual is intended to be read together with
the separate user manual provided with your bi-
cycle. Be sure to read all provided documents in-
cluding labels on the product before your first ride.
u Read ALL accompanying manuals before riding
the bike for the first time. Your Bosch Drive Sys-
tem comes with additional manuals and documents
provided by the manufacturer of the bicycle and
other components. Failure to read and understand
safety information can result in death or serious in-
jury.
u Take responsibility for your own SAFETY. If you
have any questions or do not understand some-
thing, consult with your dealer or the bicycle or
component manufacturer.
u Some eBike accessories may present a choking
hazard to small children. Keep these accessories
away from children.
CAUTION
u The Bosch Drive System adds weight to your bi-
cycle which you may not be used to lifting. Avoid
injury, use proper lifting techniques.
Using your Manual
In addition to the functions shown here, changes to
software relating to troubleshooting and functional
enhancements may be introduced at any time.
Graphics
The bicycle shown in this manual may differ slightly
from your bicycle, but will be similar enough to help
you understand our instructions.
RIGHT-HAND and LEFT-HAND sides are determined
by facing in the direction the bicycle will travel when
going forward. When you see a broken line (------), the
item referred to is hidden from view.
On-product warning labels
This device complies with part 15 of the FCC Rules.Operation is subject to the following two conditions:(1)This device may not cause
harmful interference,and(2) this device must accept any interference received.including interference that may cause undesired operation.
For safe operation see manual. Risk of electric shock.Indoor use only.Charge only batteries of the
Bosch eBike Systems.Other batteries may burst causing personal damage.Do not replace the plug
assembly as risk of fire or electric shock may result.
Otras baterías podrían reventar.causando lesiones personales y daños.No reemplace el ensamblaje del enchufe,
ya que el resultado puede ser riesgo de incendio o sacudidas eléctricas.
Pour un fonctionnement sur.reportez-vous au manuel.Risque de choc electrique.Utiliser en lieu sec
uniquement A utiliser uniquement avec les batteries des systemes d’assistance electrique
eBike de Bosch.D’autres batteries risqueraient d’eclater et de causer des blessures corporelles et des dommages.
Ne pas remplacer la connectique car un risque d’incendie ou de choc electrique pourrait en resulter.
BC
Para un funcionamiento con seguridad,ver el manual Peligro de sacudida electrica. Utilice
solamente en lugares secos.Cargar únicamente baterías de sistemas eBike de Bosch.
Compact Charger
BFP
BATTERY CHARGER
E000000
eBike Battery Charger 36-4/100-230
0 275 007 906
Made in PRC
Robert Bosch GmbH, Reutlingen
Input: 100V - 230V 50-60Hz 2.2A
Output: 36V 4A
C US
170593
WARNING
AVERTISSEMENT
ADVERTENCIA
Ne pas remplacer la connectique car un risque d'incendie ou de choc électrique pourrait en résulter.
eBike de Bosch. D
'autres batteries risqueraient d'éclater et de causer des blessures corporelles et des dommages.
uniquement. A utiliser uniquement avec les batteries des systèmes d‘assistance électrique
Pour un fonctionnement sûr, reportez-vous au manuel. Risque de choc électrique. Utiliser en lieu sec
ya que el resultado puede ser riesgo de incendio o sacudidas eléctricas.
Otras baterías podrían reventar, causando lesiones personales y da
ños. No reemplace el ensamblaje del enchufe,
solamente en lugares secos. Cargar únicamente baterías de sistemas eBike de Bosch.
Para un funcionamiento con seguridad, ver el manual Peligro de sacudida eléctrica. Utilice
assembly as risk of fire or electric shock may result.
the Bosch eBike Systems. Other batteries may burst causing personal damage. Do not replace the plug
For safe operation see manual. Risk of electric shock. Dry location use only. Charge only batteries of
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
A
B
BPF
A
Wide range charger
B
Compact charger
A short version of important safety warnings in Eng-
lish, French and Spanish with the following content
can be found on the bottom side of the charger
(marked with number(4) in the representation on the
graphics page):
– For safe operation, see manual.
– Risk of electric shock
– Indoor use only
– Charge only batteries for the Bosch eBike Systems.
Other batteries may burst causing personal dam-
age.
– Do not replace the plug assembly as risk of fire or
electric shock may result.
