Bosch BDU490P - Product Description and Specifications

Product Description and
Specifications
(1)
(2)
(3)
(4)
(5)
(17)
(6)
(13)
(12)
(7)
(8)
(9)
(10)
(11)
(19)
(1)
On-board computer
(2)
Display
(3)
Bike light button
(4)
On/off button for on-board computer
(5)
Holder for on-board computer
(6)
USB port
(7)
Operating unit
(8) Next page/scroll right button >
(9)
Select button
(10) Previous page/scroll left button <
(11) Decrease assistance level button –/
scroll down button
(12) Increase assistance level button +/
scroll down button
(13)
Push assistance button
(17)
USB port protective cover
A)
(19)
Holder for operating unit
A)
Available as spare part
