Furnace
size
Return-air
inlet
Speed
External static pressure (in. WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
100C
Bottom or
Sides
H
CFM 2195 2158 2116 2072 2031 1985 1940 1896 1852 1862
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ 40.3 41.0 41.8 42.7 43.6 44.6 45.6 46.7 47.8 47.5
Mid-H
CFM 2008 1963 1924 1882 1836 1791 1744 1697 1648 1603
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ 44.1 45.1 46.0 47.0 48.2 49.4 50.8 52.2 53.7 55.2
Mid
CFM 1753 1709 1666 1627 1573 1530 1487 1444 1395 1347
Temp Rise-1st stage ℉ -- -- -- 35.4 36.6 37.6 38.7 39.9 41.3 42.7
Temp Rise-2nd stage ℉ 50.5 51.8 53.1 54.4 56.3 57.9 59.5 61.3 63.5 65.8
Mid-L
CFM 1447 1388 1338 1286 1241 1186 1137 1083 1029 983
Temp Rise-1st stage ℉ 39.8 41.5 43.0 44.7 46.4 48.5 50.6 53.2 55.9 58.5
Temp Rise-2nd stage ℉ 61.2 63.8 -- -- -- -- -- -- -- --
Low
CFM 1089 1021 946 883 820 751 685 625 565 520
Temp Rise-1st stage ℉ 52.8 56.4 60.8 -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ -- -- -- -- -- -- -- -- -- --
100D
Bottom or
Sides
H
CFM 2283 2239 2193 2143 2095 2049 1998 1947 1897 1847
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ 38.8 39.5 40.4 41.3 42.3 43.2 44.3 45.5 46.7 48.0
Mid-H
CFM 2086 2038 1988 1942 1889 1841 1792 1745 1695 1637
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ 42.4 43.5 44.5 45.6 46.9 48.1 49.4 50.7 52.3 54.1
Mid
CFM 1813 1760 1711 1657 1609 1560 1506 1453 1402 1350
Temp Rise-1st stage ℉ -- -- -- -- 35.8 36.9 38.2 39.6 41.0 42.6
Temp Rise-2nd stage ℉ 48.8 50.3 51.8 53.4 55.0 56.8 58.8 60.9 63.1 --
Mid-L
CFM 1487 1417 1360 1296 1241 1183 1123 1064 1005 941
Temp Rise-1st stage ℉ 38.7 40.6 42.3 44.4 46.4 48.7 51.3 54.1 57.2 61.1
Temp Rise-2nd stage ℉ 59.5 62.5 -- -- -- -- -- -- -- --
Low
CFM 1122 1036 977 889 802 731 646 586 532 485
Temp Rise-1st stage ℉ 55.6 58.9 64.7 -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ -- -- -- -- -- -- -- -- -- --
120D
Bottom or
Sides
H
CFM 2290 2253 2213 2170 2127 2080 2031 1985 1937 1888
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ 46.4 47.2 48.0 49.0 50.0 51.1 52.3 53.5 54.9 56.3
Mid-H
CFM 2079 2037 1993 1950 1907 1856 1813 1767 1726 1675
Temp Rise-1st stage ℉ -- -- -- -- -- -- -- -- 40.0 41.2
Temp Rise-2nd stage ℉ 51.1 52.2 53.3 54.5 55.7 57.3 58.6 60.1 61.6 63.4
Mid
CFM 1809 1764 1719 1668 1620 1572 1528 1487 1432 1364
Temp Rise-1st stage ℉ -- -- 40.2 41.4 42.6 43.9 45.2 46.5 48.2 50.6
Temp Rise-2nd stage ℉ 58.7 60.2 61.8 63.7 65.6 67.6 69.6 -- -- --
Mid-L
CFM 1489 1429 1373 1311 1265 1208 1137 1083 1032 972
Temp Rise-1st stage ℉ 46.4 48.3 50.3 52.7 54.6 57.2 60.7 63.8 66.9 --
Temp Rise-2nd stage ℉ -- -- -- -- -- -- -- -- -- --
Low
CFM 1123 1051 1352 899 814 741 688 605 551 507
Temp Rise-1st stage ℉ 61.5 65.7 -- -- -- -- -- -- -- --
Temp Rise-2nd stage ℉ -- -- -- -- -- -- -- -- -- --
Table 4 Air Delivery - CFM (Without Filter) * **
* A fi lter is required for each return air inlet. This table shows the airfl ow
performance without a fi lter. To determine airfl ow performance with a fi lter, if a
3/4 inch (19 mm) washable media fi lter is used, assume an additional 0.1 in. WC
available external static pressure.
** The manufacturer default fan settings are based on model, refer to Table 24.
