Bosch Climate 5000 Series Ductless Air Conditioner / Heat Pump Multi Zone Outdoor Units Service Manual
08.2020 | Bosch Thermotechnology Corp.Data subject to change
8 Troubleshooting
Safety
WARNING: ELECTRICAL HAZARD
f Electricity power is still kept in capacitors even though
power supply is shut off. Do not forget to discharge the
electricity in capacitor.
Figure 24
Electrolytic Capacitors
(HIGH VOLTAGE! CAUTION!)
The value of resistance is between 1500Ƅ to 2000Ƅ.
The voltage in P3 and P4 in outdoor PCB is about 310V.
The voltage in P5 and P6 in outdoor PCB is about 310V.
