Bosch 96% AFUE Gas Furnace User's Information Manual
11.2018 | Bosch Thermotechnology Corp.
Data subject to change
2 Introduction
This Bosch 96% AFUE Gas Furnace has been designed for quality, performance,
and comfort, for years to come! Bosch strongly recommends that you read through
this manual to learn about how the furnace operates, as well as some basic
maintenance and up-keep to ensure your furnace is always running at its optimal
performance.
3 Furnace Components
The furnace below is shown in the upfl ow orientation (your furnace may have been
installed in a diff erent orientation)
Figure 1
1
2
3
4
5
6
7
9
8
10
11
12
Component Identifi cation:
1. Air Inlet
2. Primary Heat Exchanger
3. Exhaust
4. Burners
5. Gas Valve
6. Condensate Collector
7. Inducer
8. Secondary Heat Exchanger
9. Pressure Switch
10. Door Safety Switch
11. Circulating Fan Motor
12. Circulating Fan Blower
