Bosch BPC3400 - Page 59

English – 12
(11)
(24)
(1)
(2)
(23)
(7)
(6)
(21)
(5)
(25)
All representations of bike components are schematic
and can deviate from your eBike.
(1)
Key for the battery lock
(2)
Battery lock
(5)
Socket for charging connector
(6)
Operation/battery charge indicator
(7)
On/off button
(9)
Locking mechanism
(11)
Axial rail
(21)
CompactTube battery (axial)
(23)
Safety restraint for CompactTube battery
(axial)
(24)
CompactTube unlocking element
a)
(25)
CompactTube holding element
a) Designs may vary
0 275 U07 3PX | (20.03.2023) Bosch eBike Systems
