MY20B01-32_1.0_21.06.2019
29
Overview
3.4.7 Lighting
3.4.8 PowerPack 300 battery
3.4.9 PowerPack 400 battery
3.4.10 PowerPack 500 battery
3.4.11 PowerTube battery
3.4.12 Purion display
3.4.13 USB port
Applicable to motors: Performance Line Cruise,
Performance Line Speed and Performance Line CX
Voltage about 6/12 V
Maximum output
Front light 8.4/17.4 W
Rear light 0.6/ 0.6 W
Applicable to motors: ActiveLine and ActivLine Plus
Voltage about 12 V
Maximum output
Front light 17.4 W
Rear light 0.6 W
Table 20: Lighting technical data
Nominal voltage 36 V
Nominal capacity 8.2 Ah
Energy 300 Wh
Weight 2.5/ 2.6 kg
Protection class IP54
Operating temperature -5 °C - +40 °C
Storage temperature -10 °C - +60 °C
Permitted charging temperature
range
0 °C – + 40 °C
Table 21: PowerPack 300 battery technical data
Nominal voltage 36 V
Nominal capacity 11 Ah
Energy 400 Wh
Weight 2.5/ 2.6 kg
Protection class IP54
Operating temperature -5 °C - +40 °C
Storage temperature -10 °C - +60 °C
Permitted charging temperature
range
0 °C – + 40 °C
Table 22: PowerPack 400 battery technical data
Nominal voltage 36 V
Nominal capacity 13.4 Ah
Energy 500 Wh
Weight 2.6/ 2.7 kg
Protection class IP54
Operating temperature -5 °C - +40 °C
Storage temperature -10 °C - +60 °C
Permitted charging temperature
range
0 °C – + 40 °C
Table 23: PowerPack 500 battery technical data
Nominal voltage 36 V
Nominal capacity 13.54 Ah
Energy 500 Wh
Weight 2.8 kg
Protection class IP54
Operating temperature -5 °C - +40 °C
Storage temperature -10 °C - +60 °C
Permitted charging temperature
range
0 °C – + 40 °C
Table 24: PowerTube battery technical data
Internal lithium ion battery 2 × 3 V CR2016
Operating temperature -5 °C - +40 °C
Storage temperature -10 °C - +50 °C
Charging temperature 0 °C – + 40 °C
Protection rating
(with USB cover closed)
IP54
Weight about 0.1 kg
Table 25: Purion display technical data
Charge voltage 5 V
Charging current Max. 500 mA
Table 26: USB port technical data
