English | 8
Automotive Aftermarket Battery Charger | C3 | June 2010
1. Charger
2. Mounting hook
3. AC Power cord (to connect to 120V outlet)
4. Charging cable with cable lug (red and black)
4a. Cable fuse
5. DC clip for (+) Terminal (red)
6. DC clip for (–) Terminal (black)
7. Standby / power indicator
- Blue LED ring indicates standby
8. Mode selection button
- Charger has to be connected to the battery
9. Reverse polarity protection indicator
- Red LED indicates reverse hook up
10. Charging indicator
- Flashing LED indicates charging in process
11. Charge status indicator
- Illuminated LED indicates fully charged battery
and charger is operating in the trickle charging
mode
12. Mode 1
6V
– 6V output (for batteries in garden
tools, motorcycles, classic cars, etc.)
13. Mode 2 – 12V output (for motorcycle
batteries)
14. Mode 3 – 12V output (for car or marine
batteries)
15. Mode 4 – 12V output (for batteries at
temperatures <41⁰°F or for AGM batteries)
16. 12V operation indicator
3 Control Panel / List of Parts
4 Technical Data
Primary Input voltage AC: 120V / 60 Hz
Current: 1.2 A(rms) / 60 W
Secondary Rated output voltage: 6.3 V
12.6 V
Charging voltage: 14.7 V (± 0.25 V),
14.4 V (± 0.25 V),
7.2 V (± 0.25 V)
Charging current: 3.5 A (± 10 %),
0.8 A (± 10 %)
Degree of protection: IP 65 (dustproof, splash water proof)
Battery type: 6 V / 12 V lead acid battery (AGM, WET, GEL, open and VRLA)
Battery capacity: 6 V:1.2 Ah–14Ah / 12 V:1.2 Ah–120 Ah
Fuse (internal): 1.6 A
Ambient temperature: 0 °C to + 40 °C / 32 °F to 104 °F
Dimensions: 185 x 81 x 55 mm / 7
1
/
4
" x 3
1
/
4
" x 2
1
/
8
" (L x W x H)
