Product Information
Climate 5000 M – 6721849820 (2022/11)
34
2Product Information
2.1 Declaration of conformity
The design and operating characteristics of this product comply with the
European and national requirements.
The CE marking declares that the product complies with all the
applicable EU legislation, which is stipulated by attaching this
marking.
The complete text of the Declaration of Conformity is available on the
Internet: www.bosch-industrial.co.uk.
2.2 Unit components
Wall-mounted indoor unit CL2000 UW... E/CL3000i UW... E /
CL5000i UW... E - legend for figure 1:
[1] Top panel
[2] Space for small filter
[3] Air filter
[4] Back of the display
[5] Button for manual operation
[6] Airflow panel
Wall-mounted indoor unit CL6000i UW... E - legend for figure2:
[1] Top panel
[2] Air filter
[3] Space for two small filters
[4] Movement sensor (Human sensor)
[5] Button for manual operation
[6] Airflow panel
[7] Display
Built-in ducted indoor unit - legend for figure 3:
[1] Air inlet
[2] Electric control box
[3] Air filter
[4] Air Outlet
Cassette indoor unit CL5000iU 4CC... and CL5000iL 4C... - legend
for figure 4 and 5:
[1] Display
[2] Air inlet grille
[3] Air inlet
[4] Air Outlet
Rack-mounted unit CL5000iU CN... - legend for figure 6:
[1] Air Outlet
[2] Display
[3] Refrigerant pipe
[4] Condensate pipe
[5] Air inlet grille / air inlet
Outdoor unit - legend for figure 7:
[1] Fan cover
[2] Refrigerant pipe
[3] Connecting cable (to indoor unit)
[4] Gas and liquid valve
2.3 Operating temperature range
Table 27 CL2000 UW... E/CL3000i UW... E /CL5000i UW... E/CL6000i
UW... E
Table 28 CL5000iU D.../CL5000iU... C/CC/CL5000iU CN...
The built-in protection device may prevent the appliance from operating
at temperatures outside the above range.
If the humidity is more 80 %, condensation may form at the air outlet.
To prevent this, open the vertical ventilation flaps as wide as possible
(vertical relative to the ground) and set a high fan output.
Room temperature Outside temperature
Cooling 17 °C ... 32 °C -15 °C ... 50 °C
Heating 0 °C ... 30 °C -15 °C ... 24 °C
Dehumidifying 10 °C ... 32 °C 0 °C ... 50 °C
Room temperature Outside temperature
Cooling 16 °C ... 32 °C -15 °C ... 50 °C
Heating 0 °C ... 30 °C -15 °C ... 24 °C
Dehumidifying 10 °C ... 32 °C 0 °C ... 50 °C
