en Installation instructions
20
11.
Insert the grease filters.
12.
Connect the appliance to the power supply.
Fitting the air recirculation deflector
1.
Push the air recirculation deflector onto the air-pipe
connector until the air recirculation deflector audibly
engages.
2.
To change the air circulation, turn the air recircula-
tion deflector clockwise or anti-clockwise.
3.
Wind up the cable on the air recirculation deflector.
Removing the appliance
Note:The design profiles are not hand grip elements.
Do not lift the appliance by the design profiles.
1.
Remove the design profiles.
2.
Undo the upper 2 nuts on the appliance bracket.
3.
Remove the appliance from the wall.
