24" (600 mm) with side
strips removed.
Minimum hole size for drain
hose is 1 1/2" (38.1 mm).
Minimum hole size if drain
hose and inlet hose are
through same hole is 2"
(50.8 mm).
Remove the toe panel(s) (Part H or Parts I and J depending on model) (1)
from the unit and retain for attachment to the front at a later time. Loosen
the leg levelers slightly. Remove junction box cover and retain for later use
(2). Discard the small piece of protective styrofoam.
4
" (102 mm)
2" (51 mm)
24 - 24
1
/
4
" (610-616 mm)*
90°
24" (610 mm)
33
7
/
8
" (86 cm) min
1
1
2
2
8
