Strip outer casing of
electrical wire to expose
3" (76.2 mm) of the inner
wires. Then strip 1/2" (12.7
mm) casing from each
individual wire.*
* If the dishwasher will be
plugged into an electric
receptacle, contact
customer service
(1-800-735-4328) to order
approved power cord
accessory kit (SKU #
SGZPC001UC).
Flip unit back upright,
ensuring waterline is not
pinched.
Remove strain relief plate. Do not
discard! This will be reinstalled
later.
6
8
Do Not Over-tighten or
Remove Terminal Screws
7
Dishwasher Electrical Rating
VoltsHertz AmperesWatts
12060121,450 (max)
10
To Next Page
