Noise/Vibration Information
3 600 HC1 H.. 3 600 HC1 J..
Noise emission values determined according to EN 50636-2-91.
Typically the A-weighted noise levels of the product are:
– Sound pressure level dB(A)
76 79
– Sound power level dB(A)
90 92
– Uncertainty K dB
= 1.0 = 1.0
Vibration total values ah (triax vector sum) and uncertainty K determined according to EN 50636-2-91
– Vibration emission value a
h
m/s
2
< 2.5 < 2.5
– Uncertainty K m/s
2
= 1.5 = 1.5
Mounting and Operation
Action Figure Page
Product features
A 35
Delivery scope
B 36
Removing the transport safety
C 36
Connecting the shaft
D 37
Adjusting the Handle
E 37
Mounting the protection guard
F 38
Connecting the extension cable
Switching On and Off
G 38
Removing the line spool
H 39
Winding line on spool
I 39
Mounting the line spool
J 40
Line feeding
K 40
Maintenance, Cleaning and Stor-
age
L 41
Accessories
M 41
Assembly
u Caution: Switch the garden tool off and pull the mains
plug before performing any maintenance.
Connect shaft (see figures C and D)
Note: A connected shaft can no longer be dismounted.
Remove the transport safety (7).
Connect the individual parts of the shaft until they can be
heard to engage.
Mounting and adjusting the handle (see figure E)
The handle (1) can be set to different positions. To change
the adjustment, press buttons (5) and move the handle to
the desired position. Release the buttons (5) again so that
the handle can engage.
Mounting the protection guard (see figure F)
Position the protection guard (6) on the trimmer head and
fasten it with the provided screw.
Operation
u Pay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the machine.
u Caution: Switch the garden tool off and pull the mains
plug before adjusting or cleaning.
u The cutting line continues to rotate for a few seconds
after the trimmer is switched off. Allow the motor/cut-
ting line to stop rotating before switching on again.
u Do not briefly switch off and on again several times in
a row.
u Only use Bosch approved cutting elements. Cutting
performance will vary with different cutting elements.
Switching On and Off (see figure G)
To switch on, firstly press the lock-off button (2). Then
press the On/Off switch (3) and keep it pressed.
To switch off, release the On/Off switch (3).
Dismounting the spool, winding up the cutting
line and mounting the spool (see figures J to H)
u Remove the mains plug before replacing the spool.
Press both latches of the spool cover together and remove
the spool cover (9). Afterwards, remove the empty spool
(10).
Cut off approx. 4.0 m line from the refill roll. Slide one end of
the cutting line into the hole for line wind-up (11) in the
spool and wind up the cutting line uniformly and tightly.
Slide the other end of the cutting line through the hole for
line guiding (12) in the trimmer head and mount the spool
back into the trimmer head. Affix the spool by mounting the
spool cover .
Line Feeding (see figure K)
Semi-automatic Line Feeding
