Bosch ENV Series - Environmental, Mechanical, and Misc

Lens 26x Zoom (3.5–91.0 mm)
F1.6 to F3.8
Focus Automatic with manual override
Iris Automatic with manual override
Field of View 2.3° to 55°
Video Output 1.0 Vp-p, 75 Ohm
Gain Control Off / Auto (with adjustable limit)
Synchronization Line-lock (–120° to 120° vertical phase
adjust) or internal crystal
Aperture Correction Horizontal and vertical
Digital Zoom 12x
Horizontal Resolution 470 TVL (NTSC) / 460 TVL (PAL)
Sensitivity (Minimum Usable Video: 20 IRE)
Day Mode
w/Slow Shutter Off
0.33 lux
Night Mode
w/Slow Shutter Off
0.066 lux
Day Mode
w/Slow Shutter On
0.0103 lux
Night Mode
w/Slow Shutter On
0.0021 lux
Sensitivity (Usable Video:
50 IRE)
Day Mode
w/Slow Shutter Off
1 lux
Night Mode
w/Slow Shutter Off
0.26 lux
Day Mode
w/Slow Shutter On
0.026 lux
Night Mode
w/Slow Shutter On
0.052 lux
SNR >50 dB
White Balance 2000 K to 10,000 K
Camera 18x Monochrome
Imager 1/4 in. Exview HAD CCD
(752 x 582 CCIR) / (768 x 494 EIA)
Lens 18x Zoom (4.1–73.8 mm)
F1.4 to F3.0
Focus Automatic with manual override
Iris Automatic with manual override
Field of View 2.7° to 48°
Video Output 1.0 Vp-p, 75 Ohm
Gain Control Off / Auto (with adjustable limit)
Synchronization Line-lock (–120° to 120° vertical phase
adjust) or internal crystal
Aperture Correction Horizontal and vertical
Digital Zoom 12X
Horizontal Resolution 520 TVL (typical)
Sensitivity (Minimum
Usable Video: 20 IRE)
0.031 lux
Sensitivity (Usable Video:
50 IRE)
0.1 lux
SNR >50 dB
White Balance N/A
Environmental
Humidity 0% to 100% relative, condensing
Ingress Protection IP66 (NEMA 4X)
Operating Temp –40°C to 50°C (–40°F to 122°F)
Storage Temp –40°C to 60°C (–40°F to 140°F)
Mechanical
Weight 5.9 kg (13 lb)
Pan/Tilt 360° continuous pan,
–5° to 90° tilt from horizontal plane
Pre-position Speed 360°/sec., ±0.50° Accuracy
Variable Speed 120°/sec.
Miscellaneous
Sectors/Titling 16 independent sectors with
16-character titles/sector
Camera Setup/Control Bi-Phase, RS-232, RS-485, Bilinx (coax)
Communications
Protocols
Bi-Phase, Bilinx, Pelco P, and Pelco D
Pre-positions 99, each with 16-character titles
Guard Tours Two (2) types of tours:
• Recorded tours - two (2), total
duration 15 minutes
• Preset tour - one (1), consisting of
up to 99 scenes, consecutively
Addressing FastAddress Remote Addressing or 4 digit
thumbwheel
Supported Languages English, French, German, Spanish,
Portuguese, and Polish
Agency Listings CE, UL
User Connections
Power (Camera) 21-28 VAC, 50/60 Hz –15 W max.
Power (Heater) 21-28 VAC, 50/60 Hz –30 W max.
Bi-Phase ± Control Data
4 | ENV Series EnviroDome Camera Systems
