Operation instructions
29
5 Operation instructions
Fig. 38
1 On/Off button
2 Reset button
3 Program Key
4 LCD display
5 Up button
6 Down button
7 LED - Power On indicator or Stand-by
5.1 LCD Display functions
Fig. 39 Power bar indicator
Fig. 40 Temperature indicator
Fig. 41 Error indicator
Fig. 42 Lock indicator
Fig. 43 Flame indicator
Fig. 44 Remote control
Warning: Do not use any cleaning or
corrosive agent to clean the window.
