28 | Table Belt Drive Motor EC Series
EC SeriesT111970289 (2015/01) Subject to change without prior notice
TABLE BELT DRIVE MOTOR
Model Voltage
Code
Rated Voltage Voltage Min/
Max
Compressor Total Unit
w/ Belt Drive Motor
Compressor Service
Cold
Winding
Resistance
Run
Capacitor
(µF/V)
QTY RLA
(each)
LRA
(each)
Motor
Qty
FLA Min Circuit
Amps
Max
Fuse/
HACR
Single
Phase R-C
Single
Phase
S-C
Three
Phase
Line-Line
072 1 208-230/1/60 197/253 2 13.0 74 1 7 36.3 45 0.82 1.63 - 40/370
3 208-230/3/60 197/253 2 7.8 68 1 3.6 21.2 25 - - 1.15 -
4 460/3/60 414/506 2 3.9 34 1 1.8 10.6 15 - - 4.61 -
096 1 208-230/1/60 197/253 2 15.7 84 1 8.4/9.8 47.6/45.1 50/60 0.54 1.60 - 45/370
3 208-230/3/60 197/253 2 11.0 88 1 4.8/6.2 29.5/31.0 40/40 - - 0.93 -
4 460/3/60 414/506 2 5.4 44 1 2.4/3.1 14.6/15.2 15/20 - - 3.59 -
5 575/3/60 518/632 2 4.4 36 1 2.0/2.6 11.9/12.5 15/15 - - 5.68 -
120 1 208-230/1/60 197/253 2 26.3 134 1 9.8 69.0 90 0.45 0.79 - 80/370
3 208-230/3/60 197/253 2 15.6 110 1 6.2/9.2 41.3/44.3 50/50 - - 0.68 -
4 460/3/60 414/506 2 7.8 52 1 3.1/4.3 20.6/21.9 25/25 - - 3.20 -
5 575/3/60 518/632 2 5.8 39 1 2.6/3.7 15.7/16.8 20/20 - - 5.33 -
150 3 208-230/3/60 197/253 2 19.2 136 1 9.2 52.4 70 - - 0.60 -
4 460/3/60 414/506 2 8.7 66 1 4.3 23.9 30 - - 2.52 -
5 575/3/60 518/632 2 6.9 55 1 3.7 19.2 25 - - 3.74 -
151 3 208-230/3/60 197/253 2 19.2 136 1 9.2 52.4 70 - - 0.60 -
4 460/3/60 414/506 2 8.7 66 1 4.3 23.9 30 - - 2.52 -
5 575/3/60 518/632 2 6.9 55 1 3.7 19.2 25 - - 3.74 -
180 3 208-230/3/60 197/253 2 22.4 149 2 6.2 62.8 80 - - 0.56 -
4 460/3/60 414/506 2 10.6 75 2 3.2 30.1 40 - - 2.27 -
5 575/3/60 518/632 2 7.7 54 2 2.6 22.5 30 - - 3.56 -
181 3 208-230/3/60 197/253 2 22.4 149 1 12.2 62.6 80 - - 0.56 -
4 460/3/60 414/506 2 10.6 75 1 6.1 30.0 40 - - 2.27 -
5 575/3/60 518/632 2 7.7 54 1 5.4 22.7 30 - - 3.56 -
210 3 208-230/3/60 197/253 2 29.5 195 2 4.8 76.0 100 - - 0.40 -
4 460/3/60 414/506 2 14.7 95 2 2.4 37.9 50 - - 1.59 -
5 575/3/60 518/632 2 12.2 80 2 2 31.5 40 - - 2.55 -
240 3 208-230/3/60 197/253 2 30.1 225 2 6.2 80.1 110 - - 0.35 -
4 460/3/60 414/506 2 16.7 114 2 3.1 43.8 60 - - 1.36 -
5 575/3/60 518/632 2 12.2 80 2 2.6 32.6 40 - - 2.55 -
242 3 208-230/3/60 197/253 2 30.1 225 2 6.2 80.1 110 - - 0.35 -
4 460/3/60 414/506 2 16.7 114 2 3.1 43.8 60 - - 1.36 -
5 575/3/60 518/632 2 12.2 80 2 2.6 32.6 40 - - 2.55 -
300 3 208-230/3/60 197/253 2 48.1 245 2 9.2 126.6 150 - - 0.28 -
4 460/3/60 414/506 2 18.6 125 2 4.3 50.5 60 - - 1.24 -
5 575/3/60 518/632 2 14.7 100 2 3.7 40.5 50 - - 1.88 -
360 3 208-230/3/60 197/253 2 55.8 340 2 12.2 150.0 200 - - 0.21 -
4 460/3/60 414/506 2 26.9 173 2 6.1 72.7 90 - - 0.83 -
5 575/3/60 518/632 2 23.7 132 2 5.4 64.1 80 -
- 1.27 -
