Bosch GCL 2-15 User Manual

English | 17
Bosch Power Tools 1 609 92A 32T | (22.6.16)
24 Telescopic rod (BT 350)*
25 Laser viewing glasses*
* The accessories illustrated or described are not included as
standard delivery.
Technical Data
Assembly
Inserting/Replacing the Batteries
Alkali-manganese batteries are recommended for the meas-
uring tool.
– Fold open the battery lid 7 and insert the batteries. When
inserting, pay attention to the correct polarity according to
the representation on the inside of the battery compart-
ment.
If the batteries become weak, the battery capacity indicator 3
will flash green. The laser lines will also flash every 10 mins for
approx. 5 s. The measuring tool can be operated for approx.
1 hour after the first flashing. If the batteries become empty,
the laser lines will flash again directly before automatic shut-
off.
Always replace all batteries at the same time. Only use batter-
ies from one brand and with the identical capacity.
Point and line laser GCL 2-15 GCL 2-15 G
Article number
3 601 K66 E.. 3 601 K66 J..
Working range
1)
–Laser line
– Upward laser point
– Downward laser point
15 m
10 m
10 m
15 m
10 m
10 m
Levelling accuracy
–Laser lines
–Laser points
±0.3 mm/m
±0.7 mm/m
±0.3 mm/m
±0.7 mm/m
Self-levelling range, typically
±4° ±4°
Levelling duration, typically
<4s <4s
Operating temperature
–10 °C ... +50 °C –10 °C ... +50 °C
Storage temperature
–20 °C ... +70 °C –20 °C ... +70 °C
Relative air humidity, max.
90 % 90 %
Laser class
22
Laser type
–Laser point
–Laser line
630–650 nm, <1 mW
630–650 nm, <1 mW
500–540 nm, <1 mW
630–650 nm, <1 mW
Colour of laser beam
red green
C
6
11
Divergence
–Laser point
–Laser line
0.8 mrad (full angle)
0.5 mrad (full angle)
0.8 mrad (full angle)
0.5 mrad (full angle)
Tripod mount 1/4", 5/8" 1/4", 5/8"
Batteries
3 x 1.5 V LR06 (AA) 3 x 1.5 V LR06 (AA)
Operating duration in operating mode
– Cross-line and point operation
– Cross-line operation
– Line and point operation
– Line operation
–Point operation
6h
8h
12 h
16 h
22 h
6h
8h
10 h
12 h
22 h
Weight according to EPTA-Procedure
01:2014
0.49 kg 0.49 kg
Dimensions
– without rotating mount
– with rotating mount
112 x 55 x 106 mm
132 x 81 x 163 mm
112 x 55 x 106 mm
132 x 81 x 163 mm
Degree of protection
IP 54 (dust and splash water protected) IP 54 (dust and splash water protected)
1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation).
The measuring tool can be clearly identified with the serial number 11 on the type plate.
OBJ_BUCH-2637-002.book Page 17 Wednesday, June 22, 2016 4:13 PM

Bosch GCL 2-15 Specifications

General

Laser Diode	635 nm, < 1 mW
Laser Class	2
Working Range	15 m
Leveling Accuracy	± 0.3 mm/m
Self-Leveling Range	± 4°
Dust and Splash Protection	IP54
Power Supply	3 x 1.5 V LR6 (AA)
Tripod Thread	1/4"
Weight	0.49 kg
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +70°C
Levelling Time	4 s
Battery Life	Up to 8 hours
